| Model |
DTN-25 |
DTN-35 |
DTN-50 |
DTN-63 |
DTN-75 |
DTN-100 |
DTN-150 |
DTN-200 |
| Primary Voltage(V) |
380 |
380 |
380 |
380 |
380 |
380 |
380 |
380 |
| Rated Input Capacity(KVA) |
25 |
35 |
50 |
63 |
75 |
100 |
150 |
200 |
| Rated Input Current(A) |
66 |
94 |
132 |
166 |
197 |
263 |
394 |
526 |
| Rated Duty Cycle(%) |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
| Secondary Voltage Adjust Step |
— |
— |
— |
— |
— |
— |
— |
— |
| Secondary No-load Voltage(V) |
0.5-3.52 |
0.5-4.3 |
0.5-5 |
0.5-6.7 |
0.5-7.04 |
0.5-7.6 |
0.5-8.20 |
0.5-10 |
| Electrode Arm Extension Length(mm) |
430 |
430 |
430 |
430 |
450 |
450 |
450 |
450 |
| Horn Spacing(mm) |
220 |
220 |
220 |
220 |
300 |
300 |
300 |
300 |
| Upper Electrode Working Stroke(mm) |
25-100 |
25-100 |
25-100 |
25-100 |
25-100 |
25-100 |
25-100 |
25-100 |
| Max.Electrode Force(N) |
5000 |
5000 |
5000 |
5000 |
8000 |
8000 |
8000 |
8000 |
| Electrode Size(mm) |
Electrode Arm |
Φ60 |
Φ60 |
Φ60 |
Φ60 |
Φ65 |
Φ65 |
Φ65 |
Φ65 |
| Electrode Holder |
Φ25 |
Φ25 |
Φ25 |
Φ25 |
Φ25 |
Φ25 |
Φ25 |
Φ25 |
| Convex pad |
110*130 |
110*130 |
110*130 |
110*130 |
110*130 |
110*130 |
110*130 |
110*130 |
| Welding Thickness(mm) |
Low Carbon Steel |
2+2 |
2.5+2.5 |
3+3 |
3.5+3.5 |
4+4 |
5+5 |
5.5+5.5 |
6+6 |
| Stainless Steel |
0.8+0.8 |
0.9+0.9 |
1+1 |
1.2+1.2 |
1.5+1.5 |
2+2 |
2.5+2.5 |
3+3 |
| Aluminum |
0.3+0.3 |
0.4+0.4 |
0.5+0.5 |
0.6+0.6 |
0.7+0.7 |
0.8+0.8 |
0.9+0.9 |
1+1 |
| Compressed Air Pressure（mpr） |
0.6 |
0.6 |
0.6 |
0.6 |
0.6 |
0.6 |
0.6 |
0.6 |
| Consumption Of Compressed Air(m2/h) |
12 |
12 |
12 |
12 |
22 |
22 |
22 |
22 |
| Flow Of Cooling Water（L/min） |
6 |
6 |
6 |
6 |
8 |
8 |
8 |
8 |
| Dimensions(mm) |
1030*400*1760 |
1030*400*1760 |
1030*400*1760 |
1030*400*1760 |
1115*470*1950 |
1115*470*1950 |
1115*470*1950 |
1115*470*1950 |
| Weight（KG） |
250 |
260 |
280 |
300 |
350 |
380 |
400 |
420 |
| Suggest Input Wire Cross-sectional Area(mm2) |
8 |
16 |
16 |
16 |
16 |
25 |
35 |
50 |
