Sign Stud Welder
- The sign-welding machine is a kind of welding equipment which can be used for the power storage, which can release the strong current in a flash and weld the badge to the steel plate or the screw steel end.
- It is mainly used in various kinds of steel mills or large storage and transportation bases, for the welding of screw or steel plates.
- The valve special plate welder is mainly applied to the welding of stainless steel or carbon steel valve signs, and the unmarked welding is achieved.
Description
| Model | BP-15 | BP-15-G | GB-VRS16(valve) | RSR-DPI(portable) |
| Welding Current Output Mode | electrolytic capacitor | |||
| Capacitor Model(uF) | 72000 | 108000 | 108000 | 72000 |
| Power(W) | 500 | 800 | 800 | 500 |
| Input Fuse(A) | 10 | |||
| Charging Voltage(V) | 35-200 | |||
| Welding Time(S) | 0.001-0.003 | |||
| Welding Speed(pcs/min) | 15-40 | |||
| Power Voltage(V) | AC220 | AC220 | AC220 | DC12 |
| Protection Grade | IP31 | |||
| Welding Range(mm) | sign welding nail ￠4.4 | |||
| Torch Cable(m) | 3(can customized) | |||
| Weight(KG) | 16 | 18 | 22 | 28 |
| Dimensions(mm) | 480*220*300 | 480*220*300 | 480*220*300 | 480*220*300 |
